Functions and Features
• Aluminium alloy shell with exquisite craftsmanship and streamlined appearance, cast aluminum spray coated shell with light weight, good heat dissipation, and strong corrosion resistance.
• Integrated structure, with strong integrity. The pump head and driver are integrated, eliminating installation difficulties.
• 7 inch large screen, clear and easy to operate with a seven inch color LCD touch screen
• Servo motor drives high-precision operation, high torque, and low noise
• Multiple working modes: Offers flow mode, time dispensing mode, external control mode for flexible adaptation to various scenarios.
• Multiple sensing technologies for lid opening and pump stopping, as well as liquid leakage and pump stopping (optional), enhance safety.
• Three-level user permission management: Secure protection against unauthorized parameter changes
• Selected top-tier brand materials: Quality assured through meticulous selection of materials from top brands.
• Patented calibration method: Shortens calibration time by three times compared to conventional methods, reduces liquid usage by three times.
Specifications
Flow range: 2.2-33000mL/min
Speed range: 0.1-350rpm/min
Speed resolution: 0.1rpm/min, speed accuracy within 0.2%
Working time: 0.01-99.99S/M/H
Dispensing time: 0-9999
Dispensing interval time: 0.1-999.9S/M/H
Suction angle: 0-360°
Adjust: Touch screen operation
Display: 7 inch IPS color screen
Direction: Clockwise/counterclockwise
Power supply: AC 100-240V 50Hz-60Hz
Work mode: Key control start and stop, direction, full speed, state memory (power-off memory). Foot switch control, external control start/stop and direction, with physical isolation, flow mode, volume dispensing mode, time dispensing mode.
Communication interface: RS485, RS232, Ethernet support Modbus protocol
External control signal input: Analog speed regulation method (0-5V/0-10V/4-20mA), control start/stop, clockwise/counterclockwise steering, external control signal photoelectric isolation
External control signal output: External control signal 5-24V wide range input, control start/stop, clockwise/counterclockwise steering,external control signal photoelectric isolation
Wattage: <350W
Working environment: Temperature 0 – 40℃, relative humidity＜80%
Dimension(L×W×H): 440X383X295mm(pump head included)
Diver weight: 24KG(pump head included)
IP grade: IP66/IP67
Applicable Pump Head and Tube,Speed, Flow
| Drive Type | Pump Head | Channel | Tube | Single Channel Flow Rate |
| MF133 | PL48 | 1 | 92# | 9.4-33100 mL/min |
| 1 | 193# | 2.2-7759 mL/min | ||
| 1 | 88# | 4-13800 mL/min | ||
| 1 | 191# | 8.2-28690 mL/min |
Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually using it is effected by specific factors such as pressure, medium etc. Above for reference only.
Dimension(mm)
Application fields:
Biopharmaceuticals, Mining, Petrochemical, Food Industry, and More
Typical applications:
Raw Liquid Transfer, Polycarboxylic Acid Synthesis Equipment, Mining Flotation Reagent Addition, etc.
