Functions and Features
. It can be adapted to 13#, 14#, 19#, 16#, 25#, 15#, 0.5*0.8, 2*1 tube.
. It has the function of controlling the start and stop of flow mode and the start of dispensing mode.
.Power indicator and working states indicator.
Technical Parameters
| Project | Parameter |
| Suitable Tube | 13# 14# 19# 16# 25# 15# 0.5*0.8 2*1 |
| Keypad | Trigger-operated |
| Display Method | Indicator Light |
| Applicable Power Supply | DC 12V |
| Applicable Current | <10mA |
| Working Environment | Temperature 0~40°C, Relative humidity<80% |
| Dimensions | 175x61x44(mm) |
| Weight | 0.15kg |
| Degree of Protection | IP41 |
Accessories Table(Optional)
| Accessories List | Description |
| GDT-ZT-1A with fixed set of needles | Suitable for 13#,0.5*0.8 type tube |
| GDT-ZT-3A with fixed set of needles | Suitable for 14#, 19#, 2*1 type tube |
| GDT-ZT-6A with fixed set of needles | Suitable for 16#, 25#,15# tube |
Dimensions(mm)
